Disassembly order
For convenience, disassembly procedures should be followed in a particular order. Use the following
table to determine the sequence in which to access major workstation components.
Table 5-3 Workstation component installation
To install/replace... Remove... Then
remove...
Then
remove...
Then
remove...
Then
remove...
Battery, front bezel, hard drive,
memory, power supply, rear
system fan, side access panel
sensor, or solenoid lock
Chassis lock Side access
panel
Processor Chassis lock Side access
panel
Heatsink
Expansion card (PCI/PCIe) Chassis lock Side access
panel
Expansion card
support
Expansion card
slot cover
Front panel I/O assembly, optical
bay filler, optical drive, power
button assembly, or system
speaker
Chassis lock Side access
panel
Front bezel
System board Chassis lock Side access
panel
Expansion card
support
Expansion
cards or DIMMs
Heatsink
Removing the cable lock (optional)
If a cable lock is installed on the workstation, remove it before servicing the workstation.
