Brocade Converged Enhanced Ethernet Administrator's Guide v6.1.2_cee (53-1001258-01, June 2009)

Converged Enhanced Ethernet Administrator’s Guide 85
53-1001258-01
LLDP configuration procedures
6
LLDP configuration procedures
NOTE
To see the minimum configuration required to enable CEE on the Brocade 8000 CEE switch, refer
to “FCoE minimum configuration” on page 130.
NOTE
You need to enter either the copy running-config startup-config command or the write memory
command to save your configuration changes to Flash so that they are not lost if there is a system
reload or power outage.
In this section:
•Enabling and disabling LLDP globally . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
•Configuring LLDP global command options. . . . . . . . . . . . . . . . . . . . . . . . . . 86
•Configuring LLDP interface-level command options . . . . . . . . . . . . . . . . . . . 90
•Clearing LLDP-related information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
•Displaying LLDP-related information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Enabling and disabling LLDP globally
The protocol lldp command enables LLDP globally on all interfaces unless it has been specifically
disabled on an interface. LLDP is globally enabled by default.
To enable or disable LLDP globally, perform the following steps from Privileged EXEC mode:
Step Task Command
1. Enter global configuration mode. switch#config t
Enter configuration commands, one per
line. End with CNTL/Z.
switch(config)#
2. Enable LLDP globally. switch(config)#protocol lldp
switch(conf-lldp)#no disables
Disable LLDP globally. This command does not
alter the configuration settings made using the
protocol lldp commands.
switch(conf-lldp)#disable
This command returns all configuration settings
made using the protocol lldp commands to their
default settings.
switch(config)#no protocol lldp
3. Display the LLDP configuration. switch(conf-lldp)#do show lldp
[interface | neighbors | statistics]
