86 Converged Enhanced Ethernet Administrator’s Guide
53-1001258-01
LLDP configuration procedures
6
Configuring LLDP global command options
After entering the protocol lldp command from global configuration mode, you are in LLDP
configuration mode which is designated with the switch(conf-lldp)# prompt. Using the keywords in
this mode, you can set non-default parameter values that apply globally to all interfaces.
In this section:
•Specifying a system name for the Brocade 8000 CEE switch . . . . . . . . . . . 86
•Specifying an LLDP system description for the CEE switch . . . . . . . . . . . . . 86
•Specifying a user description for LLDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
•Enabling and disabling the receiving and transmitting of LLDP packets . . 87
•Configuring the transmit frequency of LLDP packets . . . . . . . . . . . . . . . . . . 87
•Configuring the hold time for receiving devices . . . . . . . . . . . . . . . . . . . . . . 88
•Configuring the advertisement of optional LLDP TLVs . . . . . . . . . . . . . . . . . 88
•Configuring the advertisement of LLDP DCBX -related TLVs . . . . . . . . . . . . 88
•Configuring FCoE priority bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
•Configuring LLDP profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Specifying a system name for the Brocade 8000 CEE switch
To specify a system name for the Brocade 8000 CEE switch, perform the following steps from the
global LLDP configuration mode:
Specifying an LLDP system description for the CEE switch
To specify an LLDP system description for the CEE switch, perform the following steps from the
global LLDP configuration mode:
Step Task Command
1. Specify an LLDP system name for the CEE switch.
By default, the “host-name” from the
chassis/entity MIB is used.
switch(conf-lldp)#system-name NAME
2. Display the LLDP configuration. switch(conf-lldp)#do show lldp
[interface | neighbors | statistics]
Step Task Command
1. Specify a system description for the Brocade
8000 CEE switch. We recommend that you
use the operating system version for the
description or use the description from the
chassis/entity MIB. The system description
is seen by neighboring switches.
switch(conf-lldp)#system-description LINE
2. Display the LLDP configuration. switch(conf-lldp)#do show lldp [interface
| neighbors | statistics]
