90 Converged Enhanced Ethernet Administrator’s Guide
53-1001258-01
LLDP configuration procedures
6
Configuring LLDP interface-level command options
To configure LLDP interface-level command options, perform the following steps from the interface
level:
6. Configure the transmission
frequency of LLDP updates. By
default the global values are
used.
switch(conf-lldp-profile-example)#hello seconds
7. Configure the hold time for
receiving devices. By default
the global values are used.
switch(conf-lldp-profile-example)#multiplier value
8. Display the LLDP configuration. switch(conf-lldp-profile-example)#do show lldp
[interface | neighbors | statistics]
switch(conf-lldp-profile-example)#do show running
lldp
Step Task Command
1. Apply an LLDP profile to an interface. There
can only be one LLDP profile at a time per
interface. If you do not use the lldp profile
option at the interface level, the global
configuration is used on the interface. If
there are no global configuration values
defined, the global default values are used.
switch(conf-if-te-0/10)#lldp profile NAME
2. Configure the FCoE priority bits for an
interface. The value is specified as
0x0-0xff.
switch(conf-if-te-0/10)#fcoe-priority-bits
VALUE
3. Configure the DCBX version for an
interface. For detailed information on these
version command keywords, see “DCBX
interaction with other vendor devices” on
page 83. The default is auto
switch(conf-if-te-0/10)#lldp version {auto
| cee | pre-cee}
4. Display the LLDP configuration. switch(conf-if-te-0/10)#do show lldp
[interface | neighbors | statistics]
Step Task Command
