Converged Enhanced Ethernet Administrator’s Guide 93
53-1001258-01
Chapter
7Configuring ACLs using the CEE CLI
In this chapter
•ACL overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
•Default ACL configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
•ACL configuration guidelines and restrictions . . . . . . . . . . . . . . . . . . . . . . . . 94
•ACL configuration procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
ACL overview
NOTE
In the Brocade Fabric OS v6.1.2_cee release, only Layer 2 MAC access control lists (ACLs) are
supported.
ACLs filter traffic for the Brocade 8000 CEE switch and permit or deny incoming packets from
passing through interfaces that have the ACLs applied to them. You can apply ACLs on VLANs and
on Layer 2 interfaces. Each ACL is a unique collection of permit and deny statements (rules) that
apply to packets. When a packet is received on an interface, the switch compares the fields in the
packet against any ACLs applied to the interface to verify that the packet has the required
permissions to be forwarded. The switch compares the packet, sequentially, against each rule in
the ACL and either forwards the packet or drops the packet.
The switch examines ACLs associated with features configured on a given interface. As packets
enter the switch on an interface, ACLs associated with all inbound features configured on that
interface are examined. With MAC ACLs you can identify and filter traffic based on the MAC
address, EtherType, and Layer 2 protocol-specific information such as VLAN ID.
The primary benefits of ACLs are as follows:
• Provide a measure of security.
• Save network resources by reducing traffic.
• Block unwanted traffic or users.
• Reduce the chance of denial of service (DOS) attacks.
