ACL configuration procedures
7
Modifying a MAC ACL
With existing MAC ACLs, you can add and remove rules. You cannot change existing rules, however,
you can remove the rule and then recreate it with the desired changes.
If you need to add more rules between existing rules than the current sequence numbering allows,
you can use the resequence command to reassign sequence numbers. For detailed information,
see “Reordering the sequence numbers in a MAC ACL” on page 99.
NOTE
Using the permit and deny keywords, you can create many different rules. The examples in this
section provide the basic knowledge needed to modify MAC ACLs.
To modify a MAC ACL, perform the following steps from Privileged EXEC mode:
7. Create a rule in the MAC ACL to permit or deny
the host source MAC address and the host
destination MAC address. Additionally:
• You can access control by EtherType (ipv4,
fcoe, arp or custom EtherType). Custom
EtherType values range between 1536 and
65535.
• Use the count option for the rule to show
how many packets hit that entry.
switch(conf-macl-ext)#{permit | deny}
host HHHH.HHHH.HHHH host
HHHH.HHHH.HHHH [custom EtherType value
| arp | count | ipv4 | fcoe]
8. Use the seq option to insert a rule anywhere in
the MAC ACL.
switch(conf-macl-std)#seq 5 {permit |
deny} HHHH.HHHH.HHHH HHHH.HHHH.HHHH
Step Task Command
1. Enter global configuration mode. switch#config t
Enter configuration commands, one per
line. End with CNTL/Z.
switch(config)#
2. Specify the ACL that you want to modify. In this
example, the extended MAC ACL name is
“test_02.”
switch(config)#mac access-list
extended test_02
switch(conf-macl-ext)#
3. Create a rule in the MAC ACL. Use a sequence
number to specify a position for the rule in the
ACL. Without a sequence number, the rule is
added to the end of the rules.
Example:
switch(conf-macl-ext)#seq 100 deny any
any
4. Remove a rule from the MAC ACL. switch(conf-macl-ext)#no seq 100
switch(conf-macl-ext)#
5. Modify sequence number 100 by recreating it
with new parameters.
switch(conf-macl-ext)#seq 100 permit
any any
Step Task Command
