Converged Enhanced Ethernet
8
PFC configuration is now complete with the CEE Priority Table defining what CoS map to a PGID and
combined with CEE Priority Group Table indicating PFC On or Off for that Priority Group.
Creating a CEE map
Example of creating a CEE map enter CEE-Map CLI configuration submode.
switch:admin>cmsh
switch>enable
switch#configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
switch(config)#cee-map test
switch(config)#exit
switch#
Mapping a priority group table
TABLE 23 Default CEE priority table
CoS PGID
015.6
115.7
215.5
315.4
415.3
515.2
615.1
715.0
Step Task Command
1 Enter global configuration mode.
switch#configure terminal
2 Create a CEE map. In this example, the name
‘test’ is used.
switch(config)#cee-map test
Step Task Command
1 Enter global configuration mode.
switch#configure terminal
2 Specify the name of the CEE map to define. In
this example ‘test’ is used.
switch(config)#cee-map test
3 Define the CEE map with for PGID 0. switch(config-ceemap)#
priority-group-table 0 weight 50 pfc
4 Define the CEE map with for PGID 1. switch(config-ceemap)#
priority-group-table 1 weight 50
