Converged Enhanced Ethernet
8
Example of defining a CEE map with a Priority Group Table.
switch:admin>cmsh
switch>enable
switch#configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
switch(config)#cee-map test
switch(config-ceemap)#priority-group-table 0 weight 50 pfc
switch(config-ceemap)#priority-group-table 1 weight 50
switch(config-ceemap)#exit
switch(config)#exit
switch#
Mapping a priority-table
Example of defining a CEE map with a Priority-to-Priority Group Table
switch:admin>cmsh
switch>enable
switch#configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
switch(config)#cee-map test
switch(config-ceemap)#priority-table 1 1 0 0 1 1 1 15.0
switch(config-ceemap)#exit
switch(config)#exit
switch#
PGID PG% PFC Description
15 - N IPC
050YSAN
150NLAN
Step Task Command
1 Enter global configuration mode.
switch#configure terminal
2 Specify the name of the CEE map to define. In
this example ‘test’ is used.
switch(config)#cee-map test
3 Define the map. switch(config-ceemap)#
priority-table 1 1 0 0 1 1 1 15.0
Priority PGID
01
11
20
30
41
51
61
715
