Applying a CEE provisioning map
Example of applying the CEE provisioning map on an interface.
switch:root>cmsh
switch>enable
switch#configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
switch(config)#interface tengigabitethernet 0/2
switch(conf-if-te-0/2)#cee test
switch(conf-if-te-0/2)#exit
switch(config)#exit
switch#exit
Verifying the CEE maps
Step Task Command
1 Enter global configuration mode.
switch#configure terminal
2 Specify the 10-gigabit Ethernet interface. In
this example, 0/2 is used.
switch(config)#interface
tengigabitethernet 0/2
3 Apply the CEE map on the interface. In this
example, the CEE map name ‘test’ is used.
switch(conf-if-te-0/2)#cee test
Step Task Command
1 Enter global configuration mode.
switch#configure terminal
2 Verify the CEE map provisioning for a specified
name.
switch(config)#show cee maps name
