FCoE configuration procedures
9
Displaying or aborting the current configuration transaction
NOTE
The configuration changes created using the fcoelogingroup command are kept in a transaction
buffer until you save the buffer using the fabric-wide fcoelogincfg--save command. The login
configuration is saved as a transaction and to apply it you need to specifically save it.
Perform the following tasks to display or abort the current configuration transaction:
Cleaning up login groups and VN_port mappings
Perform the following tasks to cleanup login groups and VN_port mappings:
Displaying the FCoE login configuration
Perform the following tasks to display the FCoE login configuration:
Task Command
Display the current configuration transaction. switch:admin> fcoelogincfg --transshow
Abort the current configuration transaction. switch:admin> fcoelogincfg --transabort
Task Command
Perform a cleanup of all conflicting login groups
and VN_port mappings from the effective
configuration. This purges not only the conflicting
login groups but also the non-existing switches.
switch:admin> fcoelogincfg --purge
Perform a cleanup of all conflicting login groups
and conflicting VN_port mappings from the
effective configuration.
switch:admin> fcoelogincfg --purge -conflicting
Perform a cleanup of all login groups for
non-existing switches from the effective
configuration.
switch:admin> fcoelogincfg --purge -nonexisting
Task Command
Display the FCoE login configuration. Syntax is as
follows:
• -switch swwn—Displays all of the login
groups for the specified switch.
• -logingroup lgname—Displays the login
group configuration for the specified login
group.
• -saved—Displays only the effective
configuration.
switch:admin> fcoelogincfg --show [-switch swwn |
-logingroup lgname] [-saved]
Display the status of the last configuration merge
during the last fabric merge. This operand also
displays conflicting login groups and login groups
for non-existing switches.
switch:admin> fcoelogincfg --show [-mergestatus]
