Converged Enhanced Ethernet Administrator’s Guide 129
53-1001258-01
FCoE configuration procedures
9
Adding or removing VN_port devices to/from the FCoE login group
Perform the following tasks to add or remove VN_port devices to/from the FCoE login group:
Deleting an FCoE login group
Perform the following task to delete an FCoE login group:
Renaming an FCoE login group
Perform the following task to rename an FCoE login group:
Task Command
Add VN_port devices to the FCoE login group.
Syntax is as follows:
• lgname—Specify the name of the login group
to which VN_port devices are to be added.
• member—Identify the WWN of the VN_port.
The WWN must be specified in hex as
xx.xx.xx.xx.xx.xx.xx.xx. Only specified
members are allowed to log into the switch.
switch:admin> fcoelogingroup --add lgname member;
member;…
Remove VN_port devices from the FCoE login
group. Syntax is as follows:
• lgname—Specify the name of the login group
from which VN_port devices are to be
removed.
• member—Identify the WWN of the VN_port.
The WWN must be specified in hex as
xx.xx.xx.xx.xx.xx.xx.x. Only specified members
are allowed to log into the switch.
switch:admin> fcoelogingroup --remove lgname
member; member;…
Task Command
Delete an FCoE login group. Syntax is as follows:
• lgname—Specify the name of the login
group.
switch:admin> fcoelogingroup --delete lgname
Task Command
Rename an FCoE login group. Syntax is as
follows:
• lgname—Specify the name of the login group
from which VN_port devices are to be
removed.
• member—Identify the WWN of the VN_port.
The WWN must be specified in hex as
xx.xx.xx.xx.xx.xx.xx.x. Only specified members
are allowed to log into the switch.
switch:admin> fcoelogingroup --rename lgname
newlgname
