Converged Enhanced Ethernet Administrator’s Guide 133
53-1001258-01
Chapter
10Administering the switch
In this chapter
•CEE configuration management general guidelines and restrictions . . . . 133
•CEE configuration management tasks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
•Flash file management commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
•Debugging and logging commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
CEE configuration management general guidelines and restrictions
Follow these guidelines and restrictions when performing any CEE configuration management
tasks.
• The CEE configuration database is maintained in a file separate from the Fabric OS
configuration database. However, note that Fabric OS configuration management remains
unchanged.
• The CEE configuration is not affected by configUpload and configDownload commands entered
in the Fabric OS shell.
• The CEE configuration must be manually saved using the CEE CLI write and copy commands.
CEE configuration management tasks
The current configuration on the switch is referred to as the running configuration (running-config).
The running-config file can be written to non-volatile memory to save configuration changes.
Additionally, the running-config file can be saved as the startup configuration (startup-config) file.
When the switch is booted, the system reads the contents of the startup-config file and applies it to
the running-config.
Typical CEE configuration management tasks are as follows:
• Save the startup-config and running-config files to Flash.
• Upload startup-config and running-config files to a remote location.
• Upload any configuration file saved and stored in Flash to a remote location.
• Download a configuration file from a remote location to the switch to serve as the
startup-config file or the running-config file.
• Download a configuration file from a remote location to the switch Flash.
