Converged Enhanced Ethernet Administrator’s Guide 139
53-1001258-01
RMON configuration procedures
11
Configuring RMON events
Use this command to add or remove an event in the RMON event table that is associated with an
RMON alarm number.
To configure RMON events, perform the following steps from Privileged EXEC mode:
Step Task Command
1. Enter global configuration mode. switch#config t
Enter configuration commands, one per
line. End with CNTL/Z.
switch(config)#
2. Configure RMON events. By default, no RMON
events are configured. Syntax is as follows:
• event—Configure an RMON event.
• event_index—Specify the RMON event
number. The range is 1 through 65535.
• log—Generate an RMON log when the event
is triggered.
• owner owner_name—Specify an owner for
the event. The maximum number of
characters is 32.
• trap event_community—Generate an SNMP
trap when the event is triggered for the
specified SNMP community string.
switch(config)#rmon event event_index [description
event_description] [log] [owner owner_name] [trap
event_community]
3. Display RMON information. switch#show rmon [alarms [alarm_id]]
[events [event_id]] [logs [event_id]]
[statistics [stats_id]]
