Converged Enhanced Ethernet Administrator’s Guide 19
53-1001258-01
Using the CEE command line interface (CLI)
2
Accessing the CEE CLI through the console interface or through a Telnet
session
NOTE
While this example uses the admin role to log in to the switch, any role listed in the “CEE CLI RBAC
permissions” section can be used.
The procedure to access the CEE CLI is the same through either the console interface or through a
Telnet session; both access methods bring you to the login prompt.
switch login: admin
Password:
switch:admin> cmsh
switch#
To return to the Fabric OS CLI, enter the following command.
switch#exit
switch:admin>
Accessing the CEE CLI from the Fabric OS shell
To enter the CEE CLI from the Fabric OS shell, enter the following command.
switch:admin> cmsh
switch#
To return to the Fabric OS shell, enter the following command.
switch#exit
switch:admin>
Accessing CEE CLI command modes
Figure 4 shows the CEE CLI command mode hierarchy.
FIGURE 4 CEE CLI command mode hierarchy
Protocol configurationInterface configuration
Port-channel
10-Gigabit Ethernet
VLAN
CEE CLI features
CEE map
ACLs
Console and VTY (line)
configuration
Console
Virtual terminal
Global configuration
EXEC
Privileged EXEC
LLDP
Spanning-tree
