Default VLAN configuration
3
Default VLAN configuration
Table 7 lists the default VLAN configuration.
VLAN configuration procedures
NOTE
To see the minimum configuration required to enable FCoE on the Brocade 8000 CEE switch, refer
to “FCoE minimum configuration” on page 130.
NOTE
You need to enter either the copy running-config startup-config command or the write memory
command to save your configuration changes to Flash so that they are not lost if there is a system
reload or power outage.
In this section:
•Enabling and disabling a CEE interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
•Configuring the MTU on a CEE interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
•Creating a VLAN interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
•Configuring a VLAN interface to forward FCoE traffic . . . . . . . . . . . . . . . . . . 30
•Configuring a CEE interface as a Layer 2 switch port . . . . . . . . . . . . . . . . . . 31
•Configuring a CEE interface as an access interface or a trunk interface . . 31
•Configuring VLAN classifier rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
•Configuring VLAN classifier groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
•Associating a VLAN classifier group to a CEE interface . . . . . . . . . . . . . . . . 35
•Clearing VLAN counter statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
•Displaying VLAN information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
TABLE 7 Default VLAN configuration
Parameter Default setting
Default VLAN VLAN 1
Interface VLAN assignment All interfaces assigned to VLAN 1
VLAN state Active
MTU size 2500 bytes
