Converged Enhanced Ethernet Administrator’s Guide 29
53-1001258-01
VLAN configuration procedures
3
Enabling and disabling a CEE interface
To enable and disable a CEE interface, perform the following steps from Privileged EXEC mode:
NOTE
CEE interfaces are disabled by default.
NOTE
Speed negotiation—CEE interfaces do not support auto-negotiation of Ethernet link speeds. The CEE
interfaces only support 10-Gigabit Ethernet.
Configuring the MTU on a CEE interface
To configure the maximum transmission unit (MTU) on a CEE interface, perform the following steps
from Privileged EXEC mode:
Step Task Command
1. Enter global configuration mode. switch>#config t
Enter configuration commands, one
per line. End with CNTL/Z.
switch(config)#
2. Specify the CEE interface (interface 0/1 is used in
this example).
switch(config)#interface
tengigabitethernet 0/1
switch(conf-if-te-0/1)#
3. Enable the CEE interface. switch(conf-if-te-0/1)#no shutdown
switch(conf-if-te-0/1)#
Disable the CEE interface. switch(conf-if-te-0/1)#shutdown
switch(conf-if-te-0/1)#
4. Display the CEE interface configuration. switch(conf-if-te-0/1)#do show
interface tengigabitethernet
Slot/Port
Step Task Command
1. Enter global configuration mode. switch#config t
Enter configuration commands, one per
line. End with CNTL/Z.
switch(config)#
2. Specify the CEE interface (interface 0/1 is used
in this example).
switch(config)#interface
tengigabitethernet 0/1
switch(conf-if-te-0/1)#
3. Enable the CEE interface. switch(conf-if-te-0/1)#no shutdown
4. Specify the MTU value on the CEE interface. The
range is 1522 through 9208 bytes. The default is
2500 bytes.
switch(conf-if-te-0/1)#mtu value
5. Disable the CEE interface. switch(conf-if-te-0/1)#shutdown
6. Enable the CEE interface. switch(conf-if-te-0/1)#no shutdown
7. Display the CEE interface configuration. switch(conf-if-vl-10)#do show
interface tengigabitethernet Slot/Port
