VLAN configuration procedures
3
Configuring a CEE interface as a Layer 2 switch port
To configure the interface as a Layer 2 switch port, perform the following steps from Privileged
EXEC mode:
Configuring a CEE interface as an access interface or a trunk interface
Each CEE port supports admission policies based on whether the frames are untagged or tagged:
• access mode—Admit only untagged and priority-tagged frames.
• trunk mode—Admit only VLAN-tagged frames.
To configure the interface as an access interface, perform the following steps from Privileged EXEC
mode:
Step Task Command
1. Enter global configuration mode. switch#config t
Enter configuration commands, one per
line. End with CNTL/Z.
switch(config)#
2. Specify the CEE interface (interface 0/1 is used
in this example).
switch(config)#interface
tengigabitethernet 0/1
switch(conf-if-te-0/1)#
3. Enable the CEE interface. switch(conf-if-te-0/1)#no shutdown
switch(conf-if-te-0/1)#
4. Configure the interface as a Layer 2 switch port.
By default, after an interface is configured as a
Layer 2 switch port it is in access mode. For more
information, see “Configuring a CEE interface as
an access interface or a trunk interface” on
page 31.
switch(conf-if-te-0/1)#switchport
switch(conf-if-te-0/1)#
5. Display the CEE interface configuration. switch(conf-if-vl-10)#do show
interface tengigabitethernet 0/1
6. Display the CEE interface running configuration. switch(conf-if-vl-10)#do show
running-config interface
tengigabitethernet 0/1
Step Task Command
1. Enter global configuration mode. switch#config t
Enter configuration commands, one per
line. End with CNTL/Z.
switch(config)#
2. Specify the CEE interface (interface 0/1 is used
in this example).
switch(config)#interface
tengigabitethernet 0/1
switch(conf-if-te-0/1)#
3. Enable the CEE interface. switch(conf-if-te-0/1)#no shutdown
switch(conf-if-te-0/1)#
4. Configure the CEE interface as a Layer 2 switch
port. By default, after an interface is configured
as a Layer 2 switch port it is in access mode and
the default PVID is 1.
switch(conf-if-te-0/1)#switchport
