VLAN configuration procedures
3
To configure a MAC address-based VLAN classifier rule, perform the following steps from Privileged
EXEC mode:
Configuring VLAN classifier groups
VLAN classifier groups (1 through 16) can contain any number of VLAN classifier rules.
To configure a VLAN classifier group and add or delete a VLAN classifier rule, perform the following
steps from Privileged EXEC mode:
Step Task Command
1. Enter global configuration mode. switch#config t
Enter configuration commands, one per
line. End with CNTL/Z.
switch(config)#
2. Configure a MAC address-based VLAN classifier
rule.
switch(config)#vlan classifier rule 5
mac 0008.744C.7F1D
3. Display the VLAN classifier rule. switch(config)#do show vlan classifier
rule 5
Step Task Command
1. Enter global configuration mode. switch#config t
Enter configuration commands, one per
line. End with CNTL/Z.
switch(config)#
2. Create a VLAN classifier group and add a rule. switch(config)#vlan classifier group 1
add rule 1
Create a VLAN classifier group and delete a rule. switch(config)#vlan classifier group 1
delete rule 1
3. Display the VLAN classifier group. switch(config)#do show vlan classifier
group 1-16
