STP, RSTP, and MSTP configuration guidelines and restrictions
4
STP, RSTP, and MSTP configuration guidelines and restrictions
Follow these configuration guidelines and restrictions when configuring STP, RSTP, and MSTP.
• You have to disable one form of xSTP before enabling another.
• LAGs are treated as normal links and by default are enabled for STP.
• You can have 16 MSTP instances and one MSTP region.
• Create VLANs before mapping them to MSTP instances.
• The switch supports up to 65 MSTP instances.
• For load balancing across redundant paths in the network to work, all VLAN-to-instance
mapping assignments must match; otherwise, all traffic flows on a single link.
• When you enable MSTP by using the global protocol spanning-tree mstp command, RSTP is
automatically enabled.
• For two or more switches to be in the same MSTP region, they must have the same
VLAN-to-instance map, the same configuration revision number, and the same name.
Default STP, RSTP, and MSTP configuration
Table 9 lists the default STP, RSTP, and MSTP configuration.
Table 10 lists the switch defaults that apply only to MSTP configurations.
TABLE 9 Default STP, RSTP, and MSTP configuration
Parameter Default setting
Spanning-tree mode By default, STP, RSTP, and MSTP are disabled
Bridge priority 32768
Bridge forward delay 15 seconds
Bridge maximum aging time 20 seconds
Error disable timeout timer Disabled
Error disable timeout interval 300 seconds
Port-channel path cost Standard
Bridge hello time 2 seconds
Flush MAC addresses from the VLAN FDB Enabled
TABLE 10 Default MSTP configuration
Parameter Default setting
Cisco interoperability Disabled
Switch priority (when mapping a VLAN to an
MSTP instance)
32768
Maximum hops 20 hops
Revision number 0
