Brocade Converged Enhanced Ethernet Administrator's Guide v6.1.2_cee (53-1001258-01, June 2009)

Converged Enhanced Ethernet Administrator’s Guide 45
53-1001258-01
STP, RSTP, and MSTP configuration procedures
4
Table 11 lists the switch defaults for the 10-Gigabit Ethernet CEE interface-specific configuration.
STP, RSTP, and MSTP configuration procedures
NOTE
To see the minimum configuration required to enable FCoE on the Brocade 8000 CEE switch, refer
to “FCoE minimum configuration” on page 130.
NOTE
You need to enter either the copy running-config startup-config command or the write memory
command to save your configuration changes to Flash so that they are not lost if there is a system
reload or power outage.
In this section:
•STP, RSTP, and MSTP-specific configuration procedures . . . . . . . . . . . . . . . 46
•STP and RSTP-specific configuration procedures . . . . . . . . . . . . . . . . . . . . . 51
•RSTP and MSTP-specific configuration procedures . . . . . . . . . . . . . . . . . . . 51
•MSTP-specific configuration procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
•10-Gigabit Ethernet CEE interface-specific configuration . . . . . . . . . . . . . . 55
•Global STP, RSTP, and MSTP-related configuration procedures. . . . . . . . . . 63
•Clearing STP, RSTP, and MSTP-related information. . . . . . . . . . . . . . . . . . . . 64
•Displaying STP, RSTP, and MSTP-related information . . . . . . . . . . . . . . . . . . 65
TABLE 11 Default 10-Gigabit Ethernet CEE interface-specific configuration
Parameter Default setting
Spanning tree Disabled on the interface
Automatic edge detection Disabled
Path cost 2000
Edge port Disabled
Guard root Disabled
Hello time 2 seconds
Link type Point-to-point
Port fast Disabled
Port priority 128
Restrict the CEE interface from becoming a root
port.
Allow the CEE interface to become a root port.
Restrict the topology change notification BPDUs
sent on the CEE interface.
Restriction is disabled
