54 Converged Enhanced Ethernet Administrator’s Guide
53-1001258-01
STP, RSTP, and MSTP configuration procedures
4
Specifying a name for an MSTP region
In MSTP mode, use this command to assign a name to an MSTP region.
To assign a name to an MSTP region, perform the following steps from Privileged EXEC mode:
Specifying a revision number for an MSTP configuration
In MSTP mode, use this command to specify a revision number for an MSTP configuration.
To specify a revision number for an MSTP configuration, perform the following steps from Privileged
EXEC mode:
Step Task Command
1. Enter global configuration mode. switch>#config t
Enter configuration commands, one per
line. End with CNTL/Z.
switch(config)#
2. Enter MSTP mode. switch(config)#protocol spanning-tree
mstp
switch(conf-mstp)#
3. Assign a name to an MSTP region. The region
name has a maximum length of 32 characters
and is case-sensitive.
switch(conf-mstp)#region region_name
4. Display the MSTP configuration. switch(conf-stp)#do show spanning-tree
mst detail
Step Task Command
1. Enter global configuration mode. switch>#config t
Enter configuration commands, one per
line. End with CNTL/Z.
switch(config)#
2. Enter MSTP mode. switch(config)#protocol spanning-tree
mstp
switch(conf-mstp)#
3. Specify a revision number for an MSTP
configuration. The range is 0 through 255.
The default is 0.
switch(conf-mstp)#revision number
4. Display the MSTP configuration. switch(conf-stp)#do show spanning-tree
mst detail
