64 Converged Enhanced Ethernet Administrator’s Guide
53-1001258-01
STP, RSTP, and MSTP configuration procedures
4
To flush the MAC addresses from the VLAN FDB, perform the following steps:
Clearing STP, RSTP, and MSTP-related information
In this section:
•Clearing spanning-tree counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
•Clearing spanning-tree-detected protocols . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Clearing spanning-tree counters
In Privileged EXEC mode, use this command to clear spanning-tree counters on all interfaces or on
the specified interface.
To clear spanning-tree counters, perform the following steps from Privileged EXEC mode:
Step Task Command
1. Enter global configuration mode. switch>#config t
Enter configuration commands, one
per line. End with CNTL/Z.
switch(config)#
2. Use the standard method to flush the MAC
addresses from the VLAN FDB. By default, the
standard method is enabled.
switch(config)#spanning-tree
tc-flush-standard
Use the Brocade method to flush the MAC
addresses from the VLAN FDB.
switch(config)#no spanning-tree
tc-flush-standard
3. Display the spanning-tree configuration. switch(config)#do show spanning-tree
Step Task Command
1. Clear all spanning-tree counters on all
interfaces.
switch#clear spanning-tree counter
Clear the spanning-tree counters associated
with a specific port-channel or CEE port
interface. The range of port-channel numbers
is 1 through 63.
switch#clear spanning-tree counter
[interface {port-channel number |
tengigabitethernet slot/port}]
2. Display the spanning-tree configuration. switch(conf-stp)#do show spanning-tree
