Converged Enhanced Ethernet Administrator’s Guide 67
53-1001258-01
Chapter
5Configuring Link Aggregation using the CEE CLI
In this chapter
•Link aggregation overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
•LACP configuration guidelines and restrictions. . . . . . . . . . . . . . . . . . . . . . . 71
•Default LACP configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
•LACP configuration procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
•LACP troubleshooting tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Link aggregation overview
In this section:
•LAGs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
•LACP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
•Dynamic link aggregation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
•Static link aggregation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
•Brocade-proprietary aggregation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
•LAG distribution process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Link aggregation allows you to bundle multiple physical Ethernet links to form a single logical trunk
providing enhanced performance and redundancy. The aggregated trunk is referred to as a Link
Aggregation Group (LAG). The LAG is viewed as a single link by connected devices, the spanning
tree protocol, IEEE 802.1Q VLANs, and so on. When one physical link in the LAG fails, the other
links stay up and there is no disruption to traffic.
To configure links to form a LAG, the physical links must be the same speed and all links must go to
the same neighboring device. Link aggregation can be done by manually configuring the LAG or by
dynamically configuring the LAG using the IEEE 802.3ad Link Aggregation Control Protocol (LACP).
NOTE
The LAG or LAG interface is also referred to as a port-channel.
