Converged Enhanced Ethernet Administrator’s Guide 69
53-1001258-01
Link aggregation overview
5
FIGURE 6 Configuring LAGs for a top-of-the-rack CEE switch—Example 1
FIGURE 7 Configuring LAGs for a top-of-the-rack CEE switch—Example 2
Data Center Core
Brocade 8000
Switch
Brocade 8000
Switch
Data Center Network
Core Layer
Data Center Network
Aggregation Layer
Data Center Network
Access Layer
(Brocade 8000s)
Data Center Database
Server Layer
Servers Servers
Router Router
Data Center Core
Brocade 8000
Switch
Brocade 8000
Switch
Data Center Network
Core Layer
Data Center Network
Aggregation Layer
Data Center Network
Access Layer
(Brocade 8000s)
Data Center Database
Server Layer
Servers Servers
Router Router
