HP 3PAR VMware ESX Implementation Guide

NOTE: VMware and HP recommend the LSI logic adapter emulation for Windows 2003 Servers.
The LSI Logic adapter is also the default option for Windows 2003 when creating a new virtual
machine. HP testing has noted a high incidence of Windows 2003 virtual machine failures during
an ESX multipath failover/failback event when the BUS Logic adapter is used with Windows 2003
VMs.
NOTE: HP testing indicates that the SCSI timeout value for virtual machine guest operating systems
should be 60 seconds in order to successfully ride out path failovers at the ESX layer. Most guest
operating systems supported by VMware have a default SCSI timeout value of 60 seconds, but
this value should be checked and verified for each GOS installation. In particular, Red Hat 4.x
guest operating systems should have their SCSI timeout value changed from their default value of
30 seconds to 60 seconds.
This command line can be used to set the SCSI timeout on all SCSI devices presented to a Red Hat
4.x virtual machine to 60 seconds:
find /sys -name timeout | grep "host.*target.*timeout" | xargs -n 1
echo "echo 60 >"|sh
This must be added as a line in /etc/rc.local of the Red Hat 4.x guest OS in order for the
timeout change to be maintained with a virtual machine reboot.
Example of a modified /etc/rc.local file:
# cat /etc/rc.local
#!/bin/sh
#
# This script will be executed *after* all the other init scripts.
# You can put your own initialization stuff in here if you don't
# want to do the full Sys V style init stuff.
find /sys -name timeout | grep "host.*target.*timeout" | xargs -n 1 echo "echo 60 >"|shtouch /var/lock/subsys/local
Multipath Failover Considerations and I/O Load Balancing
NOTE: This section about multipathing and configuring to Round Robin policy applies to all
connectivity types: FC, FCoE, and iSCSI.
VMware ESX 3.0 - 3.5 includes failover with multipath support to maintain a constant connection
between the ESX host and the HP 3PAR StoreServ Storage array. VMware terms this multipath
support with a choice of two "path policies" called "FIXED" or "MRU". As of ESX 4.0, a third path
policy choice of "round robin" is available. The path policies can be modified on a per-HP 3PAR
StoreServ Storage-volume (LUN) basis by right-clicking the device listing and selecting the
"properties" function from the VI/vSphere client menu. A pop-up window allows you to 'manage
paths' whereby the properties of the paths to the volume that was previously selected can be
modified. Using this control, you can select the path policy, and specify which path is the active
preferred path to a volume on the storage array, or which path is the standby path within the FIXED
path policy scheme. Additionally, paths can be disabled to prevent any traffic over a specific path
to a volume on the storage array.
The VI/vSphere client GUI allows for settings to be changed only on a volume-by-volume
(LUN-by-LUN) basis. The GUI is appropriate and preferred for use in managing I/O paths within
the FIXED path policy scheme. See “Configuring Round Robin Multipathing on ESX 4.x or later for
