To set the parameters globally, install the patch and follow the instructions in “VMware ESX Release
3.5 Update 4 through ESX 4.x, ESXi 5.0 and 5.0 updates, and ESXi 5.5” (page 50).
You can also use the esxcli command to set these values on a per-device basis. If both options
(the esxcli and the advanced parameters) are used, the per-device values take precedence.
To set QFullSampleSize and QFullThreshold on a per-device level, issue the following
esxcli command:
# esxcli storage core device set --device device_name -q Q -s S
The settings do not require a reboot to take effect and are persistent across reboots.
You can retrieve the values for a device by using the corresponding list command:
# esxcli storage core device list
The command supports an optional --device parameter:
#
esxcli storage core device list --device device_name
ESX/ESXi 4.1, ESXi 5.x Additional Feature Considerations
ESX/ESXi 4.1 and ESXi 5.x introduce new features related to storage I/O control and integration
with storage arrays. HP recommends the usage of features SIOC and vStorage APIs for Array
Integration (VAAI) with ESX/ESXi 4.1, ESXi 5.x - HP 3PAR StoreServ Storage configurations.
NOTE: This section about VAAI and new additional features applies to all connectivity types:
FC, FCoE and iSCSI.
Storage I/O Control
The SIOC feature allows for a new level of monitoring and control of I/O from individual virtual
machines to an HP 3PAR StoreServ Storage array at the datastore level and across ESX/ESXi hosts
in a VMware cluster.
Further information regarding the SIOC feature and considerations for its deployment may be
found in the VMware technical white paper, Storage I/O Control Technical Overview and
Considerations for Deployment:
VMware
vStorage APIs for Array Integration (VAAI)
In partnership with VMware, HP has developed an ESX/ESXi 4.1 plugin that enables a new set
of SCSI commands to be used by ESX/ESXi 4.1 in conjunction with HP 3PAR StoreServ Storage.
VMware refers to this newly incorporated set of SCSI commands as the "primitives".
ESX extensions that make use of these primitives are collectively referred to as vStorage APIs for
Array Integration (VAAI). The VMware primitives enable an ESX/ESXi host to convey virtual machine
operations to storage hardware at a meta level instead of at the traditional data level. This reduces
operational latency and traffic on the FC fabric/iSCSI network. Some of these primitives enable
the storage hardware to participate in block allocation and de-allocation functions for virtual
machines. These primitives are also known as hardware offloads.
ESX/ESXi 4.1, ESXi 5.x Additional Feature Considerations 51
