4. Start the System Dump Analyzer and confirm that the Fibre Channel ports are usable by performing the
following commands for each device. A Link State value of 00000001 means the Fibre Channel port is
properly configured.
$ ANALYZE/SYSTEM
OpenVMS system analyzer
SDA> FC SET DEVICE FGA
SDA> FC SHOW PORT
Overview
--------
Context ........ Live from RATBRN (3.302), 13-SEP-2006 15:03:56.45
Device ......... FGA0:, PCI device ID 2422
Images ......... FW 4.00.22, SYS$PGQDRIVER X-36 linked 13-SEP-2006 10:43:38.13
FibreChannel ... Node WWID 5006.0B00.003B.48F5, Port WWID 5006.0B00.003B.48F4, Port ID 0C8B00
Structures Counters Resources State
---------- -------- --------- -----
NVRAM .............. 8268BF90 Errors/Missed ..... 0000/000 Pool (bytes) .... 0029A900 Link State ...... 00000001
FICB ............... 827172D0 KCHs .............. 00000002 Free DSDLs ...... 00000000 Port State ...... 00000000
UCB ................ 8268CB00 DIPL Interrupts ... 0068E670 Free MBDs ....... 00000000 Busy Flags ...... 00000001
UCTX ............... 8270D280 FIPL Interrupts ... 0068E670 Free FCCDs ...... 00000000 MBX Owner ....... 00000000
LSDB ............... 82717510 Asynch Events ..... 0000149C Free CRCTXs ..... 00000000 MBX Waiters ..... 00000000
Previous LSDB ...... 82717590 Asynch IOCBs ...... 00000000 Map Registers ... 00000BD0 Port Waiters .... 00000000
KDB ................ 8270D2A8 Request IOCBs ..... 000E9101 PGQ_ERLs ........ 00000000 IOCB Waiters .... 00000000
Kernel KCH ......... 82716C10 Response IOCBs .... 006EB4EA Fabric FC-LAs ... 00000039 Active FCCDs .... 00000001
Static Counters .... 827137C0 Marker IOCBs ...... 00000000 Loop FC-LAs ..... 00000000 Req Que In ...... 00000033
Dynamic Counters ... 82721950 CTR Spare #1 ...... 00000000 UCTX Spare #1 ... 8270D780 Rsp Que Out ..... 0000006A
SPDT ............... 8272B100 CTR Spare #2 ...... 00000000 UCTX Spare #2 ... 00000000 Markers Due ..... 00000000
SDA>
5. Use the System Dump Analyzer to confirm the connectivity to the SCSI/FCP Targets which are visible
through the Fibre Channel ports. An STDT Stat value of 0001 means that the SCSI/FCP Target is
available to OpenVMS:
SDA> FC SHOW STDT
SYS$PGQDRIVER - QLogic ISP24xx - FGA0 - SPDT 8272B100 - STDTs
-------------------------------------------------------------
| STDT Cred Port FP NP Appr | Act Cmd Cnf Cls | QF Seq
STDT FC-LA Port Name LID PortID | Stat I/Os I/Os I/Os I/Os I/Os | Sus Sus Pnd Pau | Seen TMOs
-------- ----- ------------------- --- ------ + ---- ---- ---- ---- ---- ---- + --- --- --- --- + ---- ----
82B84BC0 00010 5000.1FE1.5001.A3EC 091 013200 | 0001 0000 0000 0000 0000 0000 | 000 000 000 000 | 0000 0000
82B88E80 00015 5000.1FE1.0015.2D08 097 020800 | 0001 0000 0000 0000 0000 0000 | 000 000 000 000 | 0000 0000
82B7CE00 00006 5000.1FE1.0015.2C58 087 011500 | 0001 0000 0000 0000 0000 0000 | 000 000 000 000 | 0000 0000
82B8AD00 00016 5000.1FE1.5001.40D8 098 011A00 | 0001 0000 0000 0000 0000 0000 | 000 000 000 000 | 0000 0000
82B7D5C0 00007 5000.1FE1.5004.E148 08C 030800 | 0001 0000 0000 0000 0000 0000 | 000 000 000 000 | 0000 000E
SDA>
Additional Configuration Information
NOTE OpenVMS only supports Fibre Channel connection via a Fibre Channel switch. Arbitrated loop
and point-to-point topologies are not supported.
