F3726, F3211, F3174, R5135, R3816-HP Firewalls and UTM Devices NAT and ALG Configuration Guide-6PW100

7
112BConfiguring an internal server
Task Remarks
233H
Configuring an internal server
Required.
After you map the private IP address/port number of an internal
server to a public IP address/port number, hosts in external networks
can access the server located in the private network.
234H
Configuring DNS mapping
Optional.
The DNS mapping feature enables an internal host to use the domain
name to access an internal server located on the same private
network, while the DNS server resides on the public network.
46BCreating an address pool
1. From the navigation tree, select Firewall > NAT Policy > Dynamic NAT.
The dynamic NAT configuration page appears.
Figure 5 Dynamic NAT configuration page
TIP:
You can click the ID link of an ACL to view details about the ACL, and create and delete ACL rules. For
more information about ACL configuration, see Access Control Configuration Guide.
2. In the Address Pool area, click Add.
The Add NAT Address Pool page appears.
