F3726, F3211, F3174, R5135, R3816-HP Firewalls and UTM Devices NAT and ALG Configuration Guide-6PW100

10
Item Descri
p
tion
Enable track to VRRP
Configure whether to associate dynamic NAT on an interface with a VRRP group,
and specify the VRRP group to be associated if you associate dynamic NAT on an
interface with a VRRP group.
When two network devices implement both stateful failover and dynamic NAT,
• Make sure each address pool on an interface is associated with one VRRP group
only. Otherwise, the system associates the address pool with the VRRP group
having the highest group ID.
• To ensure normal switchovers between the two devices, you must add the devices
to the same VRRP group, and associate dynamic NAT with the VRRP group.
VRRP Group
48BCreating a static address mapping
1. From the navigation tree, select Firewall > NAT Policy > Static NAT.
Figure 8 Static NAT configuration page
2. In the Static Address Mapping area where static address mappings are displayed, click Add to
enter the Add Static Address Mapping page.
