Figure 9 Adding Static Address Mapping page
3. Configure a static address mapping as described in 238HTable 3.
4. Click Apply.
Table 3 Configuration item
Item Descri
p
tion
Internal VPN Instance
Specify a name of the VPN instance to which the internal IP addresses belong.
If no internal VPN instance is specified, this indicates that the internal address is
a common private network address.
Internal IP Address Enter an internal IP address for the static address mapping.
Global VPN Instance
Specify a name of the VPN instance to which the external IP addresses belong.
If no global VPN instance is specified, this indicates that the external address is
a common public network address.
Global IP Address Enter a public IP address for the static address mapping.
Network Mask
Specify the network mask for internal and public IP addresses.
If the network mask is specified, net-to-net static NAT is implemented. If no
network mask is specified, the default mask 255.255.255.255 is used. In this
case, one-to-one static NAT is delivered.
ACL Specify an ACL for static NAT.
49BEnabling static NAT on an interface
1. From the navigation tree, select Firewall > NAT Policy > Static NAT.
2. In the Interface Static Translation area, click Add to enter the Enable Interface Static Translation
page.
