F3726, F3211, F3174, R5135, R3816-HP Firewalls and UTM Devices NAT and ALG Configuration Guide-6PW100

12
Figure 10 Enabling Interface Static Translation page
3. Enable static NAT on an interface as described in 239HTable 4.
4. Click Apply.
Table 4 Configuration items
Item Descri
p
tion
Interface Name Select an interface to which static NAT is applied.
Enable track to VRRP
Configure whether to associate static NAT on an interface with a VRRP group,
and specify the VRRP group to be associated if you associate static NAT on an
interface with a VRRP group.
When two network devices implement both stateful failover and static NAT, to
ensure normal switchovers between the two devices, you need to add the
devices to the same VRRP group, and associate static NAT with the VRRP group.
VRRP Group
50BConfiguring an internal server
This section describes basic and advanced internal server settings. In the common configuration page,
you can specify the service type without setting internal ports, which use the default ports of services. In
the advanced configuration page, you need to specify the protocol type and internal ports.
113BConfigure basic internal server settings
1. From the navigation tree, select Firewall > NAT Policy > Internal Server.
The internal server configuration page appears.
