F3726, F3211, F3174, R5135, R3816-HP Firewalls and UTM Devices NAT and ALG Configuration Guide-6PW100

46
3BNAT444
The device does not support stateful failover of the NAT444 feature.
NAT444 can be configured only at the CLI.
25B
Feature and hardware compatibility
Hardware NAT444 com
p
atible
F1000-A-EI/F1000-S-EI No
F1000-E No
F5000 No
Firewall module Yes
U200-A No
U200-S No
26B
Overview
NAT444 translates an IPv4 address to another IPv4 address to a third IPv4 address. Compared to
transition technologies like DS-lite, NAT64, 6RD, and dual stack, it costs less on the accessing devices
and services by only doubling the NAT at the carrier grade.
27B
Features
82BAssigning port blocks
NAT444 applies to the scenario where multiple users use a public address for accessing services and
solves the user tracing problem by assigning port blocks.
As shown in
274HFigure 34, after NAT444 translation, internal users at 10.1.1.1 and 10.1.1.2 use the same
public address but different port numbers for accessing Internet services.
Figure 34 Assigning port blocks
