Configuring NAT444 logging
NAT444 sends the following logs to the log server when an internal user access the Internet through
NAT444:
• NAT444 user log
• NAT444 session establishment log
• NAT444 session removal log
NAT444 logs support two formats: china-telecom and china-unicom-nat444. You can configure the two
formats by executing the info-center format command. For more information about NAT444 log formats
and NAT444 logging configurations, see System Management and Maintenance Configuration Guide
and System Management and Maintenance Command Reference.
To configure NAT444 logging:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enable NAT444
logging.
nat444 log { user | session-start | session-end }
By default, NAT444 logging
is disabled.
33B
Displaying and maintaining NAT444
Task Command Remarks
Display NAT444 static IP-port
mappings.
display nat444 static-ip-port-block Available in any view.
Display NAT444 dynamic IP-port
mappings.
display nat444 dynamic-ip-port-block Available in any view.
34B
NAT444 configuration examples
90BNetwork requirements
NAT444 gateways can be designed in a MAN with BRASs or core routers (CRs) through bypass mode
to interconnect an IPv4 network with an IPv6 network.
• Bypass BRAS
