RPF prime neighbor: NULL
Join/Prune FSM: [SPT: J] [RPT: NP]
Downstream interface(s) information:
Total number of downstreams: 1
1: GigabitEthernet0/2
Protocol: pim-sm, UpTime: 02:54:43, Expires: 00:02:47
DR state: [DR]
Join/Prune FSM: [NI]
Assert FSM: [NI]
FSM information for non-downstream interfaces: None
Table 233 Command output
Field Descri
p
tion
Total 0 (*, G) entry; 1 (S, G) entry Number of (S, G) and (*, G) entries in the IPv6 PIM routing table.
(2001::2, FFE3::101) An (S, G) entry in the IPv6 PIM routing table.
RP IP address of the RP.
Protocol IPv6 PIM mode.
Flag
Flag of the (S, G) or (*, G) entry in the IPv6 PIM routing table:
• ACT—Indicates that the entry has been used for routing data.
• DEL—Indicates that the entry will be removed.
• EXPRUNE—Indicates that some outgoing interfaces are pruned by
other IPv6 multicast routing protocols.
• EXT—Indicates that the entry contains outgoing interfaces provided
by other IPv6 multicast routing protocols.
• LOC—Indicates that the entry is on a router directly connected to
the same subnet with the IPv6 multicast source.
• NIIF—Indicates that the entry contains unknown incoming
interfaces.
• NONBR—Indicates that the entry has an IPv6 PIM neighbor
searching failure.
• RPT—Indicates that the entry is on a RPT branch where (S, G)
prunes have been sent to the RP.
• SPT—Indicates that the entry is on the SPT.
• SWT—Indicates that the entry is in the process of RPT-to-SPT
switchover.
• WC—Indicates a wildcard routing entry.
Uptime Length of time since the (S, G) or (*, G) entry was installed.
Upstream interface Upstream (incoming) interface of the (S, G) or (*, G) entry.
Upstream neighbor Upstream neighbor of the (S, G) or (*, G) entry.
RPF prime neighbor
RPF neighbor of the (S, G) or (*, G) entry:
• For a (*, G) entry, if this router is the RP, the RPF neighbor of this (*,
G) entry is NULL.
• For a (S, G) entry, if this router directly connects to the IPv6 multicast
source, the RPF neighbor of this (S, G) entry is NULL.
