# Display the detailed MLD configuration and operation information on GigabitEthernet 0/2 (upstream
interface).
<Sysname> display mld interface gigabitethernet 0/2 verbose
GigabitEthernet0/2(FE80::100:CEF:FE01:101):
MLD proxy is enabled
Current MLD version is 2
Multicast ipv6 routing on this interface: enabled
Require-router-alert: disabled
Version1-querier-present-timer-expiry: off
Table 237 Command output
Field Descri
p
tion
GigabitEthernet0/1(FE80::200:AFF:FE01:101) Interface and IPv6 link-local address.
Current MLD version MLD version running on the interface.
Value of query interval for MLD (in seconds) MLD query interval, in seconds.
Value of other querier present interval for MLD (in
seconds)
MLD other querier present interval, in seconds.
Value of maximum query response time for MLD (in
seconds)
Maximum response delay for general query messages
(in seconds).
Value of last listener query interval (in seconds) MLD last listener query interval, in seconds.
Value of startup query interval(in seconds) MLD startup query interval, in seconds.
Value of startup query count Number of MLD general queries sent on startup.
General query timer expiry
Remaining time of the MLD general query timer,
where "off" means that the timer never times out.
Querier for MLD IPv6 link-local address of the MLD querier.
MLD activity
MLD activity statistics (number of join and done
messages).
Robustness MLD querier's robustness variable.
Require-router-alert
Dropping MLD messages without Router-Alert:
enabled/disabled.
Fast-leave MLD fast-leave processing status: enabled/disabled.
Ssm-mapping MLD SSM mapping status: enabled/disabled.
Startup-query-timer-expiry
Remaining time of MLD startup query timer, where
"off" means that the timer never times out.
Other-querier-present-timer-expiry
Remaining time of MLD other querier present timer,
where "off" means that the timer never times out.
Proxying interface
MLD proxy interface, where "none" means that no
proxy interface exists.
Total 1 MLD Group reported
Total number of MLD groups the interface has
dynamically joined.
MLD proxy is enabled MLD proxying is enabled.
Version1-querier-present-timer-expiry
Remaining time of the MLDv1 querier present timer,
where "off" means that the timer never times out.
