1025
Total 2 entries
00001. (*, FF1E::101)
List of 1 downstream interface
GigabitEthernet0/1 (FE80::200:5EFF:FE71:3800),
Protocol: MLD
00002. (100::1, FF1E::101), Flag: ACT
List of 1 downstream interface in include mode
GigabitEthernet0/2 (FE80::100:5E16:FEC0:1010),
Protocol: MLD
Table 239 Command output
Field Descri
p
tion
Routing table MLD routing table.
00001 Sequence number of this (*, G) entry.
(*, FF1E::101) An (*, G) entry in the MLD routing table.
Flag
MLD route flags:
• ACT—MLD routing entries that have been used for forwarding
data packets but have the multicast group address out of the
SSM group range.
• SUC—MLD routing entries that have been added to the
forwarding table and have the multicast group address within
the SSM group range.
List of 1 downstream interface
List of downstream interfaces: namely the interfaces to which
multicast data for this group will be forwarded.
in include mode Downstream interface is in the include mode.
in exclude mode Downstream interface is in the exclude mode.
Downstream interface is none No downstream interfaces exist.
Protocol Protocol type.
display mld ssm-mapping
Use display mld ssm-mapping to display the configured MLD SSM mappings for the specified IPv6
multicast group.
Syntax
display mld ssm-mapping ipv6-group-address [ | { begin | exclude | include } regular-expression ]
Views
Any view
Default command level
1: Monitor level
