F3726, F3211, F3174, R5135, R3816-HP Firewalls and UTM Devices Network Management Command Reference-6PW100

1027
range of 0 to F. If you do not specify any IPv6 multicast group, this command displays information about
all IPv6 multicast groups created based on the configured MLD SSM mappings.
interface-type interface-number: Specifies an interface by its type and number. If you do not specify any
interface, this command displays the multicast group information created based on the configured MLD
SSM mappings on all interfaces.
verbose: Displays the detailed multicast group information created based on the configured MLD SSM
mappings.
|: Filters command output by specifying a regular expression. For more information about regular
expressions, see Getting Started Guide.
begin: Displays the first line that matches the specified regular expression and all lines that follow.
exclude: Displays all lines that do not match the specified regular expression.
include: Displays all lines that match the specified regular expression.
regular-expression: Specifies a regular expression, a case-sensitive string of 1 to 256 characters.
Examples
# Display detailed information about IPv6 multicast group FF3E::101 created based on the configured
MLD SSM mappings on all interfaces.
<Sysname> display mld ssm-mapping group ff3e::101 verbose
Interface group report information
GigabitEthernet0/1(FE80::101):
Total 1 MLD SSM-mapping Group reported
Group: FF3E::101
Uptime: 00:01:46
Expires: off
Last reporter: FE80::10
Group mode: include
Source list(Total 1 source):
Source: 30::1
Uptime: 00:01:46
Expires: 00:02:34
Last-listener-query-counter: 0
Last-listener-query-timer-expiry: off
Table 241 Command output
Field Descri
p
tion
Interface group report information
IPv6 multicast group information created based on MLD SSM
mappings on the interface.
Total 1 MLD SSM-mapping Group reported One MLD SSM mapping multicast group was reported.
Group IPv6 multicast group address.
Uptime Length of time since the IPv6 multicast group was reported.
Expires
Remaining time of the IPv6 multicast group, where "off"
means that the group never times out.
Last reporter
IPv6 address of the host that last reported membership for this
group.
