The following matrix shows the value range for the instance-id argument on different firewalls and UTM
devices:
Hardware Value ran
g
e
F1000-A-EI/F1000-S-EI 0 to 15
F1000-E 0 to 15
F5000 0 to 15
Firewall module 0 to 15
U200-A 0 to 7
U200-S 0 to 7
vlan vlan-list: Specifies a VLAN list in the format of vlan-list = { vlan-id [ to vlan-id ] }&<1-10>, where the
vlan-id argument represents the VLAN ID, which ranges from 1 to 4094, and &<1-10> indicates that you
can specify up to 10 vlan-id [ to vlan-id ] parameters.
Usage guidelines
If you specify no VLAN in the undo instance command, all VLANs mapped to the specified MSTI will be
remapped to the CIST.
You cannot map the same VLAN to different MSTIs. If you map a VLAN that has been mapped to an MSTI
to a new MSTI, the old mapping will be automatically removed.
After configuring this command, run the active region-configuration command to activate the
VLAN-to-instance mapping.
Examples
# Map VLAN 2 to MSTI 1.
<Sysname> system-view
[Sysname] stp region-configuration
[Sysname-mst-region] instance 1 vlan 2
Related commands
• active region-configuration
• check region-configuration
• display stp region-configuration
region-name
Use region-name to configure the MST region name.
Use undo region-name to restore the default MST region name.
Syntax
region-name name
undo region-name
Default
The MST region name of a device is its MAC address.
