update acl [ ipv6 ] { acl-number | name acl-name }: Specifies a new ACL by its number or name to
replace the ACL already referenced by the class.
Table 51 The value range for the
match-criteria argument
Ke
y
word and ar
g
ument combination Descri
p
tion
acl [ ipv6 ] { acl-number | name acl-name }
Matches an ACL.
The acl-number argument is in the range of 2000 to 4999 for an
IPv4 ACL, and 2000 to 3999 or 10000 to 42767 for an IPv6
ACL.
The acl-name argument is a case-insensitive string of 1 to 63
characters, which must start with an English letter from a to z or A
to Z, and to avoid confusion, it cannot be all.
any Matches all packets.
dscp dscp-list
Matches DSCP values.
The dscp-list argument is a list of up to eight DSCP values. A DSCP
value ranges from 0 to 63.
destination-mac mac-address Matches a destination MAC address.
customer-dot1p 8021p-list
Matches the 802.1p priority of the customer network.
The 8021p-list argument is a list of up to eight 802.1p priority
values. An 802.1p priority ranges from 0 to 7.
ip-precedence ip-precedence-list
Matches IP precedence.
The ip-precedence-list argument is a list of up to eight IP
precedence values. An IP precedence ranges from 0 to 7.
local-precedence local-precedence-list
Matches local precedence.
The local-precedence-list argument is a list of up to eight local
precedence values. A local precedence ranges from 0 to 7.
qos-local-id local-id-value Matches a local QoS ID, which ranges from 1 to 4095.
source-mac mac-address Matches a source MAC address.
The following matrix shows the keyword ipv6 and firewalls and UTM compatibility:
Hardware Ke
y
word com
p
atible
F1000-A-EI/F1000-S-EI Yes
F1000-E Yes
F5000 Yes
Firewall module Yes
U200-A Yes
U200-S No
Usage guidelines
1. Defining an ACL-based match criterion
If the ACL referenced in the if-match command does not exist, the class cannot be applied to hardware.
