Field Descri
p
tion
giants
Inbound frames larger than the maximum frame length supported on the
interface.
• For an Ethernet interface that does not permit jumbo frames, giants
refer to frames larger than 1536 bytes (without VLAN tags) or 1540
bytes (with VLAN tags).
• For an Ethernet interface that permits jumbo frames, giants refer to
frames larger than the maximum size of Ethernet frames that are
allowed to pass through.
- throttles
Number of times that the port shut down because of buffer or CPU
overload.
CRC
Total number of inbound frames that had a normal length, but contained
checksum errors.
frame
Total number of inbound frames that contained checksum errors and a
non-integer number of bytes.
- overruns
Number of packets dropped because the input rate of the port exceeded
the queuing capability.
aborts
Total number of illegal inbound packets:
• Fragment frames—CRC error frames shorter than 64 bytes. The
length can be an integer or non-integer value.
• Jabber frames—CRC error frames greater than the maximum frame
length supported on the Ethernet interface (with an integer or
non-integer length). For an Ethernet interface that does not permit
jumbo frames, jabber frames refer to CRC error frames greater than
1518 bytes (without VLAN tags) or 1522 bytes (with VLAN tags). For
an Ethernet interface that permits jumbo frames, jabber frames refer to
CRC error frames greater than the maximum size of Ethernet frames
that are allowed to pass through the interface (which is configured
when you configure jumbo frame support on the interface).
• Symbol error frames—Frames that contained at least one undefined
symbol.
• Unknown operation code frames—Non-pause MAC control frames.
• Length error frames—Frames whose 802.3 length fields did not
accord with the actual frame length (46 to 1500 bytes).
ignored
Number of inbound frames dropped because the receive buffer of the
port ran low.
- parity errors Total number of frames with parity errors.
Output (total): 1502 packets,
138924 bytes
- unicasts, 2 broadcasts,
406 multicasts, 0 pauses
Outbound traffic statistics (in packets and bytes) for the port. All
outbound normal and abnormal packets (including unicast, broadcast,
and multicast), and pause frames were counted.
Output (normal): - packets, - bytes
1094 unicasts, -
broadcasts, - multicasts, - pauses
Outbound normal traffic (including unicast, broadcast, and multicast)
and pause frame statistics (in packets and bytes) for the interface.
output errors Outbound packets with errors.
- underruns
Number of packets dropped because the output rate of the interface
exceeded the output queuing capability. This is a low-probability
hardware anomaly.
