Usage guidelines
• After you enable the ORF capability, the local BGP router negotiates the ORF capability with the
BGP peer through Open messages. After that, the BGP router can exchange ORF information in
route-refresh messages with the peer. For non-standard ORF capability negotiation, you need also
to configure the peer capability-advertise orf non-standard command.
• After you disable the ORF capability, the local BGP router does not negotiate the ORF capability
with the specified peer or peer group.
Table 104 Description of the both, send, and receive parameters and the negotiation result
Local
p
arameter Peer
p
arameter Ne
g
otiation result
send
• receive
• both
The ORF sending capability is enabled locally and the ORF
receiving capability is enabled on the peer.
receive
• send
• both
The ORF receiving capability is enabled locally and the ORF
sending capability is enabled on the peer.
both both
Both the ORF sending and receiving capabilities are enabled
locally and on the peer.
Examples
# Enable the ORF capability for the BGP peer 18.10.0.9. Then, after negotiation, the local router can
exchange ORF information with the peer 18.10.0.9.
<Sysname> system-view
[Sysname] bgp 100
[Sysname-bgp] peer 18.10.0.9 as-number 100
[Sysname-bgp] peer 18.10.0.9 capability-advertise orf ip-prefix both
The related configuration needs to be made on the peer.
# In BGP-VPN instance view, enable the ORF capability for the BGP peer 18.10.0.9. Then, after
negotiation, the local router can exchange ORF information with the peer 18.10.0.9. (vpn1 must have
been created.)
<Sysname> system-view
[Sysname] bgp 100
[Sysname-bgp] ipv4-family vpn-instance vpn1
[Sysname-bgp-ipv4-vpn1] peer 18.10.0.9 as-number 200
[Sysname-bgp-ipv4-vpn1] peer 18.10.0.9 capability-advertise orf ip-prefix both
The related configuration needs to be made on the peer.
peer capability-advertise orf non-standard
Use peer capability-advertise orf non-standard to enable the non-standard ORF capability (the early
implementation of ORF is different from that defined in RFC) for a BGP peer or peer group.
Use undo peer capability-advertise orf non-standard to disable the non-standard ORF capability for the
BGP peer or peer group.
Syntax
peer { group-name | ip-address } capability-advertise orf non-standard
undo peer { group-name | ip-address } capability-advertise orf non-standard
