Usage guidelines
You can specify up to two next hops by performing this command once or twice.
With a next hop specified, the undo apply ip-address next-hop command removes the specified next
hop.
Without any next hop specified, the undo apply ip-address next-hop command removes all next hops.
Examples
# S e t a d i re c t l y - c o n n e c t e d n ex t h o p o f 1.1.1.1.
<Sysname> system-view
[Sysname] policy-based-route aa permit node 11
[Sysname-pbr-aa-11] apply ip-address next-hop 1.1.1.1 direct
apply ip-precedence
Use apply ip-precedence to set a precedence for packets.
Use undo apply ip-precedence to remove the configuration.
Syntax
apply ip-precedence value
undo apply ip-precedence
Views
Policy node view
Default command level
2: System level
Parameters
value: Sets the precedence for IP packets. Eight precedence values (0 to 7) are available. Each
precedence value corresponds to a precedence type, as shown in Table 108. Y
ou can set either a
precedence value or a precedence type for IP packets.
Table 108 IP precedences and the corresponding types
Precedence value
Precedence t
yp
e
0 routine
1 priority
2 immediate
3 flash
4 flash-override
5 critical
6 internet
7 network
Examples
# Set the precedence to 5 (critical) for packets.
<Sysname> system-view
