exclude: Displays all lines that do not match the specified regular expression.
include: Displays all lines that match the specified regular expression.
regular-expression: Specifies a regular expression, a case-sensitive string of 1 to 256 characters.
Examples
# Display the PIM information on all interfaces on the public network.
<Sysname> display pim interface
VPN-Instance: public net
Interface NbrCnt HelloInt DR-Pri DR-Address
GE0/1 1 30 1 10.1.1.2
GE0/2 0 30 1 172.168.0.2 (local)
GE0/3 1 30 1 20.1.1.2
Table 134 Command output
Field Descri
p
tion
VPN-Instance: public net Public network.
Interface Interface name.
NbrCnt Number of PIM neighbors.
HelloInt Hello interval.
DR-Pri Priority for DR election.
DR-Address DR IP address, where "local" indicates a local address.
# Display the detailed PIM information on GigabitEthernet 0/1 on the public network.
<Sysname> display pim interface gigabitethernet 0/1 verbose
VPN-Instance: public net
Interface: GigabitEthernet0/1, 10.1.1.1
PIM version: 2
PIM mode: Sparse
PIM DR: 10.1.1.2
PIM DR Priority (configured): 1
PIM neighbor count: 1
PIM hello interval: 30 s
PIM LAN delay (negotiated): 500 ms
PIM LAN delay (configured): 500 ms
PIM override interval (negotiated): 2500 ms
PIM override interval (configured): 2500 ms
PIM neighbor tracking (negotiated): disabled
PIM neighbor tracking (configured): disabled
PIM generation ID: 0xF5712241
PIM require generation ID: disabled
PIM hello hold interval: 105 s
PIM assert hold interval: 180 s
PIM triggered hello delay: 5 s
PIM J/P interval: 60 s
PIM J/P hold interval: 210 s
PIM BSR domain border: disabled
