VPN instance: Public network
Address Type Pool Expiration time
2:1::1 Auto(O) 1 Jul 10 2011 19:45:01
3:1::2 Static(C) 1 Jan 1 2011 11:11:11
1:1::2 Static(F) 2 Not-available
1:2::1f1 Static(O) 3 Oct 9 2011 09:23:31
# Display IPv6 address binding information about address pool 1.
<Sysname> display ipv6 dhcp server ip-in-use pool 1
Total number: 2
VPN instance: Public network
Address Type Pool Expiration time
2:1::1 Auto(O) 1 Jul 10 2011 22:22:22
3:1::2 Static(C) 1 Jan 1 2011 11:11:11
# Display the binding information about IPv6 address 2:1::1.
<Sysname> display ipv6 dhcp server ip-in-use address 2:1::1
Pool: 1
Client: FE80::C800:CFF0:FE18:0
Type: Auto(O)
DUID: 00030001CA000C180000
IAID: 0x30001
Address: 2:1::1
Preferred lifetime 400 sec, valid lifetime 500 sec
Will expire at Jul 10 2008 09:45:01 (288 seconds left)
Table 164 Command output
Field Descri
p
tion
Total number Total number of IPv6 address bindings.
VPN instance
Name of the VPN instance. Public network is displayed if the binding is on the public
network.
Address Assigned IPv6 address.
Type
Type of an IPv6 address binding:
• Static(F)—Free static binding, indicating the static address has not been assigned to
the client.
• Static(O)—Offered static binding. If the server replies with an Advertise message to
the client during the four-step message exchange, the server sets the type of the static
binding configured for the client to Static(O).
• Static(C)—Committed static binding, indicating the static IPv6 address has been
assigned to the client in a Reply message.
• Auto(O)—Offered dynamic binding. If the server selects a dynamic IPv6 address and
replies with an Advertise message to the client during the four-step message
exchange, the server sets the type of the dynamic IPv6 address binding to Auto(O).
• Auto(C)—Committed dynamic binding, indicating the dynamic IPv6 address has
been assigned to the client in a Reply message.
Pool Address pool to which the binding belongs.
Expiration time
Time when the lease of an IPv6 address expires. If the lease expires after the year 2100,
this field displays after 2100. For a free static binding, this field displays Not-available.
Client Link-local address of a DHCPv6 client. For a free static binding, this field displays null.
