Value Meanin
g
4
Indicates that the main board will synchronize the RP information of the entry
to other cards.
80
Indicates that the main board will synchronize the encapsulation group
information of the entry to other cards.
80000000 Indicates that the main board will notify other cards to add the entry.
40000000 Indicates that the main board will notify other cards to remove the entry.
Related commands
• display multicast ipv6 routing-table
• multicast ipv6 forwarding-table downstream-limit
• multicast ipv6 forwarding-table route-limit
display multicast ipv6 routing-table
Use display multicast ipv6 routing-table to display information about the IPv6 multicast routing table.
Syntax
display multicast ipv6 routing-table [ ipv6-source-address [ prefix-length ] | ipv6-group-address
[ prefix-length ] | incoming-interface { interface-type interface-number | register } | outgoing-interface
{ exclude | include | match } { interface-type interface-number | register } ] * [ | { begin | exclude |
include } regular-expression ]
Views
Any view
Default command level
1: Monitor level
Parameters
ipv6-source-address: Multicast source address.
ipv6-group-address: Specifies an IPv6 multicast group address, in the range of FFxy::/16, where x and
y represent any hexadecimal number from 0 through F.
prefix-length: Specifies the prefix length of a multicast group address or an IPv6 multicast source address.
For an IPv6 multicast group address, this argument has an effective value range of 8 to 128. For an IPv6
multicast source address, this argument has an effective value range of 0 to 128. The system default is
128 i n b o t h c a s e s.
incoming-interface: Displays the routing entries, where the incoming interface is the specified one.
interface-type interface-number: Specifies an interface by its name and number.
register: Represents a registered interface.
outgoing-interface: Displays the routing entries, where the outgoing interface is the specified one.
exclude: Displays the routing entries, where the outgoing interface list excludes the specified interface.
include: Displays the routing entries, where the outgoing interface list includes the specified interface.
match: Displays the routing entries, where the outgoing interface list includes only the specified interface.
