1. If the destination IP address and the mask are both 0.0.0.0, the configured route is a default route.
If routing table searching fails, the router will use the default route for packet forwarding.
2. Different route management policies can be implemented for different route preference
configurations. For example, specifying the same preference for different routes to the same
destination address enables load sharing, while specifying different preferences for these routes
enables route backup.
3. When configuring a static route, you can specify the output interface or the next hop address
based on the actual requirement. The next hop address must not be the IP address of the local
interface; otherwise, the route configuration will not take effect. For interfaces that support network
address to link layer address resolution or point-to-point interfaces, you can specify the output
interface or next hop address.
• For a Null 0 or loopback interface, if the output interface has already been configured, no next hop
address is required.
• For point-to-point interfaces, you can specify the output interface if you do not know the peer
address. There is no need to change the router’s configuration even if the peer address is changed.
A PPP interface obtains the peer’s IP address through PPP negotiation. In this case, you need only
specify the output interface.
• For NBMA and P2MP interfaces, which support point-to-multipoint networks, the IP address to link
layer address mapping must be established in addition to IP route configuration. HP recommends
configuring the next hop IP address when you configure the output interface.
• Do not specify a broadcast interface (such as an Ethernet interface, virtual template, or VLAN
interface) as the output interface for a static route, because a broadcast interface may have multiple
next hops. If you have to do so, you must specify the corresponding next hop of the interface at the
same time.
Related commands: ip route-static default-preference and display ip routing-table.
NOTE:
• The static route does not take effect if you specify its next hop address first and then configure the
address as the IP address of a local interface, such as Ethernet interface and VLAN interface.
• To configure track monitoring for an existing static route, simply associate the static route with a track
entry. For a non-existent static route, configure it and associate it with a track entry.
• If the track module uses NQA to detect the reachability of the private network static route's next hop, the
VPN instance number of the static route's next hop must be identical to that confi
g
ured in the NQA tes
t
group.
• If a static route needs route recursion, the associated track entry must monitor the next hop of the
recursive route instead of that of the static route; otherwise, a valid route may be mistakenly considered
invalid.
Examples
# Configure a static route, whose destination address is 1.1.1.1/24, next hop address is 2.2.2.2, tag value
is 45, and description information is for internet & intranet.
<Sysname> system-view
[Sysname] ip route-static 1.1.1.1 24 2.2.2.2 tag 45 description for internet & intranet
# Configure a static route for a VPN instance named vpn1: the destination address is 1.1.1.1/16 and the
next hop address is 1.1.1.2, which is the address of this VPN instance.
<Sysname> system-view
[Sysname] ip route-static vpn-instance vpn1 1.1.1.1 16 vpn-instance vpn1 1.1.1.2
