interface-type interface-number: Specifies an interface.
Description
Use the display rip interface command to display the RIP interface information of the RIP process.
If no interface is specified, information about all RIP interfaces of the RIP process is displayed.
Examples
# Display all the interface information of RIP process 1.
<Sysname> display rip 1 interface
Interface-name: GigabitEthernet0/0
Address/Mask:1.1.1.1/24 Version:RIPv1
MetricIn:5 MetricIn route policy:123
MetricOut:5 MetricOut route policy:234
Split-horizon/Poison-reverse:on/off Input/Output:on/on
Current packets number/Maximum packets number:234/2000
Table 50 Output description
Field Descri
p
tion
Interface-name The name of an interface running RIP
Address/Mask IP address and mask of the interface
Version RIP version running on the interface
MetricIn Additional routing metric added to the incoming routes
MetricIn route policy
Name of the routing policy used to add the additional routing metric
for the incoming routes. If no routing policy is referenced, the field
displays Not designated.
MetricOut Additional routing metric added to the outgoing routes
MetricOut route policy
Name of the routing policy used to add the additional routing metric
for the outgoing routes. If no routing policy is referenced, the field
displays Not designated.
Split-horizon
Indicates whether split-horizon is enabled (ON: enabled, OFF:
disabled)
Poison-reverse
Indicates whether poison-reverse is enabled (ON: enabled, OFF:
disabled)
Input/Output
Indicates if the interface is allowed to receive (Input) or send
(Output) RIP messages (on means it is allowed, off means it is not
allowed)
Current packets number/Maximum
packets number
Packets to be sent/Maximum packets that can be sent on the
interface
display rip route
Syntax
display rip process-id route [ ip-address { mask | mask-length } | peer ip-address | statistics ]
View
Any view
