Table 51 Output description
Field Descri
p
tion
Route Flags
R — RIP route
T — TRIP route
P — The route never expires
A — The route is aging
S — The route is suppressed
G — The route is in Garbage-collect state
Peer 21.0.0.23 on
GigabitEthernet0/0
Routing information learned on a RIP interface from the specified
neighbor
Destination/Mask Destination IP address and subnet mask
Nexthop Next hop of the route
Cost Cost of the route
Tag Route tag
Flags Indicates the route state
Sec Remaining time of the timer corresponding to the route state
# Display the routing statistics of RIP process 1.
<Sysname> display rip 1 route statistics
Peer Aging Permanent Garbage
21.0.0.23 2 0 3
21.0.0.12 2 0 4
Total 4 0 7
Table 52 Output description
Field Descri
p
tion
Peer IP address of a neighbor
Aging Total number of aging routes learned from the specified neighbor
Permanent Total number of permanent routes learned from the specified neighbor
Garbage
Total number of routes in the garbage-collection state learned from the specified
neighbor
Total Total number of routes learned from all RIP neighbors
filter-policy export (RIP view)
Syntax
filter-policy { acl-number | ip-prefix ip-prefix-name } export [ protocol [ process-id ] | interface-type
interface-number ]
undo filter-policy export [ protocol [ process-id ] | interface-type interface-number ]
View
RIP view
