172.16.0.1 Broadcast DR 1 1 172.16.0.1 0.0.0.0
Table 58 Output description
Field Descri
p
tion
Area Area ID of the interface
IP address Interface IP address (regardless of whether TE is enabled or not)
Type
Interface network type:
PTP, PTMP, Broadcast, or NBMA
State
Interface state defined by interface state machine:
• DOWN: In this state, no protocol traffic will be sent or received on the
interface.
• Waiting: Means the interface starts sending and receiving Hello packets and
the router is trying to determine the identity of the (Backup) designated router
for the network.
• p-2-p: Means the interface will send Hello packets at the interval of
HelloInterval, and try to establish an adjacency with the neighbor.
• DR: Means the router itself is the designated router on the attached network.
• BDR: Means the router itself is the backup designated router on the attached
network.
• DROther: Means the router is a DROther router on the attached network.
Cost Interface cost
Pri Router priority
DR The DR on the interface’s network segment
BDR The BDR on the interface’s network segment
display ospf lsdb
Syntax
display ospf [ process-id ] lsdb [ brief | [ { asbr | ase | network | nssa | opaque-area | opaque-as |
opaque-link | router | summary } [ link-state-id ] ] [ originate-router advertising-router-id |
self-originate ] ]
View
Any view
Default level
1: Monitor level
Parameters
process-id: OSPF process ID, in the range 1 to 65535.
brief: Displays brief LSDB information.
asbr: Displays Type-4 LSA (ASBR Summary LSA) information in the LSDB.
ase: Displays Type-5 LSA (AS External LSA) information in the LSDB.
network: Displays Type-2 LSA (Network LSA) information in the LSDB.
nssa: Displays Type-7 LSA (NSSA External LSA) information in the LSDB.
