243
OSPF Process 1 with Router ID 1.1.1.1
Neighbor Brief Information
Area: 0.0.0.0
Router ID Address Pri Dead-Time Interface State
1.1.1.2 1.1.1.2 1 40 GE0/0 Full/DR
Table 63 Output description
Field Descri
p
tion
Area Neighbor area
Router ID Neighbor router ID
Address Neighbor interface address
Pri Neighboring router priority
Dead time(s) Dead interval remained
Interface Interface connected to the neighbor
State
Neighbor state: Down, Init, Attempt, 2-Way, Exstart, Exchange,
Loading or Full
display ospf peer statistics
Syntax
display ospf [ process-id ] peer statistics
View
Any view
Default level
1: Monitor level
Parameters
process-id: OSPF process ID, in the range 1 to 65535.
Description
Use the display ospf peer statistics command to display OSPF neighbor statistics.
If no OSPF process is specified, OSPF neighbor statistics of all OSPF processes is displayed.
Examples
# Display OSPF neighbor statistics.
<Sysname> display ospf peer statistics
OSPF Process 1 with Router ID 10.3.1.1
Neighbor Statistics
Area ID Down Attempt Init 2-Way ExStart Exchange Loading Full Total
0.0.0.0 0 0 0 0 0 0 0 1 1
0.0.0.2 0 0 0 0 0 0 0 1 1
Total 0 0 0 0 0 0 0 2 2
